DSOX1EMBD, Keysight Technologies Oscilloscope Software for Use with DSOX1102A Digital Oscilloscope, DSOX1102G Digital Oscilloscope, Программное обеспечение

Keysight DSOX1EMBD Embedded Serial Triggering and Analysis for InfiniiVision DSOX1000 Series Oscilloscopes

The I²C, SPI, and UART/RS-232 serial decode option for InfiniiVision 1000 X-Series oscilloscopes (DSO models) displays responsive, time-aligned, on-screen decode of Inter-Integrated Circuit (I²C), 3-wire Serial Peripheral Interface (SPI), and UART/RS232 serial communication buses. Because it is hardware-based, this option provides the fastest throughput solution for triggering on and analyzing I²C, SPI and UART/RS-232 serial buses found in a wide variety of embedded designs.
This measurement application option works with InfiniiVision 1000 X-Series DSOX1102A and DSOX1102G models.

Features and Benefits

The fastest throughput oscilloscope solution for triggering on and analyzing I²C, SPI and UART/RS-232 serial buses
Support for the I²C serial protocol
Support for the 3-wire SPI serial protocol
On-screen serial decode time-correlated with the serial data waveforms
Protocol trigger and hardware-based protocol decode

Keysight InfiniiVision Series

Keysight InfiniiVision 2000 & 3000 X-Series offers the power of 4 instruments in 1: oscilloscope; logic analyzer; function generator; protocol analyzer. The models are fully upgradable (bandwidth, MSO, WaveGen, memory, measurement applications) to meet future requirements and protect investment.

Keysight 1000 X-Series Digital Oscilloscopes
