THM 6-1212, TRACOPOWER THM 6 DC-DC Converter, 12V dc/ 500mA Output, 9 → 18 V dc Input, 6W, PCB Mount, +90°C Max Temp -40°C, Преобразователь

Traco Power DC-DC Converter, 89% Efficiency, 5kV AC Isolation Voltage - THM 6 Series - THM 6-1212

Get energised with this DC-DC converter from Traco Power. It's a reliable and extra-safe power solution suited to medical use. The unit takes an input voltage between 9V and 18V DC and outputs a steadily regulated 12V DC. A built-in input filter helps to prevent electrical interference, making it suitable for critical healthcare and industrial functions. Thanks to a broad operating temperature range between -40°C and +90°C, you can use it in harsh conditions without loss of performance.

• Suitable for altitudes up to 5,000m, for versatile use
• PCB-mounted for easy installation
• Compact dimensions of 20.3 (W) x 31.8 (L) x 10.2mm (D)
• Isolation voltage of 5kV AC protects personnel and equipment
• Integrated DIP-24 package is low maintenance and easily replaceable

Applications

• Hospital instruments
• Industrial automation
• Measurement devices

How efficient is this DC-DC converter?

It has a high efficiency rating of 89%, which reduces power consumption and minimises heat build-up inside your device.

Does this converter experience much current leakage?

It has a low leakage current of 2μA, so you can be sure it's safe to handle without worrying about electric shocks.
