THM 10-0513, TRACOPOWER THM 10 DC-DC Converter, 15V dc/ 670mA Output, 4.5 → 9 V dc Input, 10W, PCB Mount, +90°C Max Temp, Преобразователь

Traco Power THM 10 Series, 10 Watt

The THM-10 series is a range of medical 10 Watt DC/DC converters in DIP-24 plastic package with a wide 2:1 input voltage range. They provide a reinforced isolation system for 5000 VACrms isolation and a very low leakage current of less than 2 μA. The units are approved to IEC/EN/ES 60601-1 3rd edition for 2 x MOPP (Means Of Patient Protection) and come along with an ISO 14971 risk management file. Design and production conform to the quality management system ISO 13485. With a high efficien¬cy of up to 87% and highest grade components the converters can reliably operate in an ambient temperature range of –40°C up to +90°C. They constitute a reliable solution not only for medical equipment but also for demanding ranges of application such as transportation, control & measurement or IGBT drivers.

Features and Benefits

• Wide 2:1 input voltage
• I/O isolation 5000 V ac RMS rated for 250 V ac RMS working voltage
• Certification according to IEC/EN/ES 60601-1 3rd edition for 2xMOPP
• Risk management process according to ISO 14971 including risk management file
• Acceptance criteria for electronic assemblies according to IPC-A-610 Level 3
• Low Leakage Current
• Extended operating temperature range –40°C to 90°C
• Operating up to 5000 m altitude
• 5-year product warranty A

Traco Power THM 10 Series DC-DC Converter, Isolated, Single Output - THM 10-0513

This Traco Power medical grade DC-DC converter is a reliable solution designed for various industries. With a wide input voltage range and high quality components, this converter ensures optimal performance in demanding applications.

Features & Benefits

• High power rating of 10W
• Isolated design for safety
• Wide input voltage range of 4.5V to 9V DC
• Medical approval for use in healthcare equipment
• Compact DIP 24 plastic case for easy installation
• Low leakage current for efficiency
• Operating temperature range from 40°C to +90°C for versatility
• Multiple output voltage options for flexibility
• PCB mount for secure installation

Applications

• Suitable for automation systems
• Ideal for use in electronics industries
• Perfect for Electrical equipment
• Reliable choice for mechanical applications

Can it operate in extreme temperatures?

Yes, the Traco Power medical grade DC-DC converter can operate in temperatures ranging from -40°C to +90°C with efficiency.

Will it work in medical equipment?

Yes, this converter is medical approved and designed for applications in healthcare equipment.

Is it easy to install?

Yes, with its compact DIP-24 plastic case and PCB mount design, installation is simple and secure.

Can it handle a wide input voltage range?

Yes, this converter has an input voltage range of 4.5V to 9V DC, making it suitable for various power sources.
