THM 30-2415WI, TRACOPOWER THM 30 WI DC-DC Converter, 24V dc/ 1.25A Output, 9 → 75 V dc Input, 30W, PCB Mount, Преобразователь

Traco Power DC-DC Converter, 5kV AC Isolation Voltage, 4:1 Input Ratio - THM 30 WI Series - THM 30-2415WI

Make sure your power supply hits the mark with this DC-DC converter from Traco Power. It takes a wide input range between 9 and 36V DC, making it a versatile option. After conversion, you get a 24V DC output that works with standard motors, instruments and control applications. The unit's built to handle temperatures between -40°C and +80°C without breaking a sweat, so you can trust it takes challenging conditions in its stride.

Features & Benefits

• Through-hole pins for dependable mounting on a PCB
• Reinforced insulation protects users against shocks
• 90% efficiency to keep waste heat to a minimum

Applications

• Medical equipment
• Process control
• Telecommunications

Is this DC-DC converter suitable for portable devices?

Yes. It has a small footprint of 25.4 (L) x 50.8 (W) x 10.2mm (D) to save space inside compact electronics. It features a remote on-and-off function for power-saving in battery-powered equipment. As it weighs 32g, it doesn't add unnecessary weight.

Is this DC-DC converter safe for medical equipment used by patients?

Low current leakage of 2.5μA means the unit keeps equipment touch-safe. As it meets the European standard EN 60601-1 for medical electrical equipment, you can be sure it's safe for devices used by patients.

Datasheet
