PHE450XB4220JB10R17, KEMET PHE450 Polypropylene Capacitor PP, 3kV dc, ±5%, 2.2nF, Конденсатор

KEMET PHE450 Series Metallized Polypropylene Capacitors

KEMET PHE450 series double metallized polypropelene film capacitors are encapsulated in a self-extinguishing resin in a box of material which meets UL 94 V-0 requirements. Suitable for applications with high current stress like protection circuits in switch mode power supplies and deflection circuits in televisions.

Features

Double metallised polypropylene film pulse capacitor
Rated voltage: 250 V dc to 3000 V dc
Rated voltage: 180 to 1000 V ac
Capacitance tolerance: ±5%, other tolerances on request
Lead spacing: 7.5 mm to 37.5 mm

Radial 105°C

Encapsulated in self-extinguishing material meeting the requirements of UL94V-0

Specification sheet

Series Datasheet

Series Datasheet
