MikroElektronika MIKROE-2032, PULSE Pulse Generator mikroBus Click Board for NE555, Макетная плата

PULSE click mikroBUS™

PULSE click is a mikroBUS add-on board for a pulse generation with an adjustable frequency. It features the NE555 Precision Timer which can produce highly accurate time delays. A circular central switch selects four Pulse Frequency maximum ranges; up to 100 Hz, 1 kHz, 10 kHz, and 100 kHz.

Multi-turn Trimmer Potentiometers on-board to fine-tune the desired output frequency
Output or Interrupt function selection on the mikroBUS socket with a jumper
3.3 V or 5 V output Level selection with a jumper
5 V power supply on mikroBUS socket
Dimensions 42.9 x 25.4 mm
