151192-0004, Molex, MILLI-GRID Female Connector Housing, 2mm Pitch, 4 Way, 2 Row, Корпус разъема

Molex 2.0 mm Halogen Free Milli-Grid Series Crimp Receptacle Housings

2.0 mm Milli-Grid series halogen free shrouded crimp receptacle housings with a high density 2 x 2 mm grid design and a robust mating performance. These 2.0mm Milli-Grid crimp housings feature polarization keys on either end of the housing to prevent the wrong mating orientation. A locking ramp window ensures a strong retention force to the mating header. The crimp contacts for these 2.0 mm Milli-Grid crimp receptacle housings must be purchased separately

Features and Benefits

High density 2 x 2 mm grid design
Meets Halogen free compliance requirements
Robust locking mechanism for secure mating
Polarization keys to prevent mismating

Product Application Information

These 2.0mm Milli-Grid crimp receptacle housings meet the halogen free requirements in data, consumer and other industry wire to board applications. Data Communications and telecommunications applications include storage, servers, modems, motherboards, monitors switches and routers. Consumer applications include Printers, copiers and fax machines. Other applications include automotive GPS and car audio

Molex 2.0 mm Milli-Grid Interconnection System

The Milli-Grid connector system is a high density connector system based on a 2 x 2 mm grid pattern offering design flexibility for board to board and cable to board applications. The Milli-Grid family of connectors consists of shrouded and unshrouded headers, single and dual row receptacles, connector housings and crimp terminals

MILLI-GRID Crimp Receptacle Housing - Line Drawing

MILLI-GRID Halogen-Free Shrouded Connectors - Brochure

Part Details

Product Specification

Technical Drawing - 151192-0004
