MS3106A-10SL-4S, Amphenol Industrial, MS 2 Way Free Hanging MIL Spec Circular Connector Receptacle, Socket Contacts,Shell Size 10,, Разъем

1366284
Номер производителя: MS3106A-10SL-4SПроизводитель: Amphenol Industrial
Цена за шт.
5658.90 руб. (С НДС) *

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

Amphenol MS MIL-C-5015 Circular Plug Connectors

Amphenol MS Series Class A MIL-spec connectors that meet the demanding performance requirements of MIL-C-5015. These cable mount circular plug connectors have proven electrical capability for equipment applications where durability is important. The Amphenol plugs have threaded couplings and single key/keyway shell polarization for an accurate and reliable connection. The solid shells of these MS Series circular MIL-C-5015 connectors are made from high grade aluminium alloy. The shells are electrically zinc plated with an olive drab chromate finish which ensures a high resistance to corrosion. The inserts of these military circular connectors are made from resilient synthetic rubber which offers a high dielectric strength and resistance to vibration.

Features & Benefits

Durable, field-proven design
Threaded couplings for quick and accurate mating
Keying and polarization to prevent mismating
Durable construction with high grade aluminium shell
Zinc plated olive drab chromate finish for high resistance to corrosion
Rubber inserts for high dielectric strength and resistance to vibration

Product Application Information

These Amphenol plug MS series class A Mil-Spec circular connectors are designed for to perform virtual functions in powering, testing and ground support systems. Applications include communication equipment, computers and shipboard installation where mechanical forces and physical parameters are not subject to extreme or rapid environmental changes. These MS series MIL spec circular cable mount plugs are for use with the MS Series 3100, 3101 and 3102 receptacles

Note

Order cable clamp with bushing separately
Cable-mounting plugs (pin contacts) will only mate with chassis sockets. Cable-mounting sockets will only mate with chassis plugs.

97 (Olive Drab)

Commercial grade threaded circular multi-pole connectors designed to conform to the general requirements of MIL-C-5015 and satisfy the commercial and industrial demand for quality, reliability and low cost. The connectors are screw locking and fully interchangeable with other screw locking MIL-C-5015 types. All pins and sockets solder bucket type.

Техническая спецификация
pdfAmphenol Military-Bayonet and High Tension Connectors
pdfAmphenol MIL-DTL-5015 & MIL-5015 Circular Connectors - Brochure
pdfMS5015 circular cable plug, 2 P - Line Drawing
Военный стандарт:
MIL-DTL-5015
Кол-во контактов:
2
Концевая заделка:
Припой
Материал контактов:
Медный сплав
Материал корпуса:
Алюминиевый сплав
Оболочка:
Кадмий
Ориентация корпуса:
Прямой
Покрытие контактов:
Серебро
Размер корпуса:
10
Размер разъема:
Стандартный
Род:
Female
Род контакта:
Female
Серия:
MS
Тип монтажа:
Free Hanging
Тип стыковки:
Резьбовое
