DFM-50-125-P-A-GF, Festo Pneumatic Guided Cylinder - 170875, 50mm Bore, 125mm Stroke, DFM Series, Double Acting, Пневмоцилиндр

Festo Pneumatic Guided Cylinder, 50mm Bore, G1/4 Port Connection - DFM-50-125-P-A-GF

Use this pneumatic guided cylinder from Festo to keep heavy loads on the straight and narrow. Thanks to its four slide bearings, weight and force are evenly distributed across the board, assuring you resistance to torque and lateral strain. This cylinder is quick out of the blocks and moves at speeds up to 0.6m/s so you can achieve high output rates. You'll find this is a space-efficient unit as the piston rod is incorporated into the guide body.

Features & Benefits

• Wide operating temperature range of -20°C to +80°C for use in harsh industrial conditions
• Elastomer cushioning absorbs impact, protecting the assembly while reducing vibration and sound
• Steel and aluminium alloy materials offer high-tensile strength to resist mechanical stress and give a longer service life
• Double-acting cylinder is stronger, faster and uses less energy than single-acting alternatives

Applications

• Processing and packaging plants
• Warehouse operations
• Pharmaceutical production

What size is this cylinder?

The unit measures 259 (L) x 148 (W) x 64mm (H) and the piston has a 50mm diameter, so it takes up minimal space in your setup.

Can I use lubricated media with this pneumatic cylinder?

Yes, this cylinder supports lubricated compressed air, which helps to keep the piston running smoothly.
