MS4-EE-1/4-10V24, Festo 3/2 Pneumatic Solenoid Valve - Electrical G 1/4 MS4 Series 24V dc, 542578, Клапан

Festo Pneumatic Solenoid Valve, Piston Gate Valve Design, Monostable Type - MS4-EE-1/4-10V24

Controlling airflow is a breeze with this 3/2-way Festo pneumatic solenoid valve. All it takes is a 24V DC input signal to trigger this unit's built-in poppet mechanism and change the direction of your compressed fluid. Demanding applications are no trouble for the unit, thanks to its high flow rate of2000L/min. The strong die-cast aluminium housing is corrosion-resistant, so it stands up to damp or steamy conditions.

Features & Benefits

• Broad operating temperature range between -10°C and +50°C for use in harsh environments
• IP65 rating indicates it's dust-proof and protected against low-pressure water jets from any direction
• NBR seals are abrasion-resistant to prevent leakage in vibrating settings or if knocked by accident
• 4 to 10 bar operating pressure range for reliable performance in medium-duty applications
• Mountable in any position, so you can easily adjust it to fit your work setup

Applications

• Manufacturing equipment
• Air tools
• Industrial automation and control

What thread size do the unit's connections have?

The three ports on this valve have a standard G1/4 thread, ensuring wide compatibility with commonly used pneumatic fittings.

Solenoid Operated On/Off Valves

Datasheet

MS4-EE-1/4-10V24 Specification Sheet
