RS PRO Multi-Conductor Data Cable, 0.75 mm², 2 Cores, 18 AWG, Screened, 100m, Grey Sheath, Кабель

RS PRO 2 Core CY Control Cable, Screened, 0.75 mm², 100 m

Use this two-core data cable from RS PRO in controlled environments for both analogue and digital signals. It's a good choice when you need a fixed data transmission cable in areas without pre-made cable runs.


The cable has a stranded core for easy handling and an extra braided shield layer to reduce noise transmission. It also comes fitted with a flame-retardant polyvinyl chloride (PVC) sheath for improved safety. To help you identify them easily, the internal cores are colour-coded.


This slim four-core cable is designed with a small diameter, so it will fit easily into areas where space is limited. It's ideal for carrying both control signals for machinery and audio/visual data in a studio. You can also use the cable to directly power small pieces of equipment, as it has a 300 V, 9 A current rating.

Features and Benefits

• Wire size of 18 AWG (American Wire Gauge)


• Multicore cable shape


• Copper conductor material


• Conductor resistance of 24.5 Ω/km


• Cross-sectional area of 0.75 mm²


• Current rating of 9 A


• Not an earth cable


• Flame-retardant


• Length of 100 m


• Operating temperature range of -30°C to +70°C


• Minimum bend radius of 8 x diameter


• Two cores


• Outer diameter of 5.4 mm


• Tinned copper braid screen type


• Screened


• Grey sheath colour


• Polyvinyl chloride (PVC) sheath material


• Voltage rating of 300 V
