DRL-60-12-1, TDK-Lambda DRL-60 Switch Mode DIN Rail Power Supply, 85 → 264V ac ac Input, 12V dc dc Output, 4A Output, 60W, Блок питания

DRL Series DIN Rail Power Supplies

The low profile DRL series DIN Rail power supply provides a reliable solution for many industrial applications and building automation. With double insulation and safety Class II input, connection to earth is not required. The NEC Class 2 compliant output, in accordance with UL 1310, allows operation where output currents are to be limited under fault conditions. Available in four power ranges, the DRL series provide a choice of 12 and 24 output voltages.

Features and Benefits

• Protection Class II
• No load power < 0.3 W to 0.5 W
• Universal AC input 85 V ac to 264 V ac
• 12 V and 24 V dc
• Operating temperature -20°C to +71°C

Product Application Information

• Building control
• Security and surveillance
• Climate controls
• Smart home
• Renewable energy
