US03-0001-01, Flowline US03 Series Reflective Ultrasonic Liquid Level Transmitter Level Transmitter, 2 Wire, 4 to 20 mA Output,

Flowline EchoTouch US01 & US03 Reflective Ultrasonic Liquid Level Transmitter

Flowline EchoTouch US01 & US03 intrinsically safe reflective ultrasonic level transmitter provides continuous level measurement up to 3 m with a 4 mA to 20 mA analogue signal output configurable via Flowline WebCal software. The non-contact liquid level sensor features proprietary Reflective Technology that delivers reliable level measurement in condensing environments. Typical applications include day tank, IBC or drum, cooling tower, skid or machine, process tank and waste sumps.

Features and Benefits

Reflective Technology measures reliably with condensation
Narrow 2” (5 cm) beam width for applications with limited space
Configuration is easy with WebCal software and USB adapter
Short 1.5” (3.8 cm) dead band maximises tank filling capacity
PVDF transducer and PP enclosure for corrosive environments
Fail-safe diagnostics with selectable fail-safe signal outputs
Type 6P (IP68) compact enclosure for small tank applications
Automatic temperature compensation from -40º to 80º C.
