RS PRO 120W Plug-In AC/DC Adapter 12V dc Output, 0 → 10A Output, Блок питания

RS PRO DC Power Supply

The RS PRO is a 12V high-quality adapter. This range of switch-mode power supply provides 120W of continuous output power in a high-quality compact enclosure suitable for many general power applications. It has an input frequency of 47Hz to 63Hz. While the input voltage range is 85V to 264VAC (wide range). Its range of output current is 0A to 10A. It gives fully regulated output. Most importantly, it is short circuit protected. It is a reliable product due to high MTBF of 50000h. The plug type is 3-pin IEC. It has thermal protection of latching type. The PSU would be a suitable power source for a large range of PCs except for high tech desktop. The PC power supply units can be interchanged, provided the technical specifications of the appliance meet the PSU's in terms of safety and usability.

Features and Benefits

• Universal AC input
• The desktop power supply complies with level VI energy regulations and have a high-efficiency rating
• No load power consumption is significantly less and low leakage current
• It complies with the relevant safety and EMC standards
• The power supply has a fully regulated output
• Overvoltage and short circuit protected
• Operating temperature ranges between 0°C and 40°C

Applications

• Information technology equipment (ITE) commercial
• Laptops and CCTV cameras
• Networking and peripherals
• Gaming machines

Certifications

• CCC
• CE
• CULus
• FCC
• TUV
• UL
