84137750, Sensata / Crydom 8413 Series Solid State Relay, 10 A dc Load, Panel Mount, 60 V dc Load, 32 V dc Control, Реле

Sensata | Crydom Solid-State Relay, LED Input Status Indicator, 10A Rated Load Current - GN Series - 84137750

When you need a dependable switching solution for your low-voltage DC loads, this solid-state relay from Sensata | Crydom is the way to go. Thanks to a high dielectric strength of 3700Vrms between the input and output, this workmate has excellent insulation properties to protect you from any shocking surprises during use. It also comes with a protective touch-safe cover to shield you from contact with live parts, making it the ideal choice for sensitive work settings. You'll find relays like this one used in microcontroller systems and consumer electronics applications.

Features & Benefits

• Rated load current of 10A for use in high-power applications
• Wide operating temperature range between -40°C and +100°C for use in demanding conditions
• MTBF of over 11 million hours at +40°C for long-term performance
• Low I/O capacitance of 8pF for high-integrity signal transmission

How do I know that this relay is receiving input current?

This unit comes with a green LED indicator that lights up when there's an input supply, so it's easy to monitor.

Crydom Solid State Relay and Accessories

Datasheet

Declaration of Conformity 2014/35/EU

CE Declaration of Conformity (2014/35/EU, 2015/863/EU)
