D1D12K, Sensata / Crydom 1-DC Series Solid State Relay, 12 A dc Load, Panel Mount, 100 V dc Load, 32 V dc Control, Реле

Sensata | Crydom Solid-State Relay, 3 to 32V DC Control Voltage Range, 12A Current Rating - 1-DC Series - D1D12K

Smooth out speed bumps in your switching setup with this solid-state relay from Sensata | Crydom. It switches on and off without any moving parts, so you can count on it to resist wear for a long lifespan. The robust plastic housing is resistant to impact and corrosion for added durability. Anti-rotation barriers keep the device firmly in place to prevent accidental disconnections when things get shaky You'll find this unit useful for your motion gear, HVAC systems and medical devices.

Features & Benefits

• Self-extinguishing housing for safety in the event of a fire
• Hex standoffs for secure wiring
• Safe for use in challenging conditions, thanks to a wide operating temperature range between -40°C and +100°C
• Light weight of 75.5g to place minimal strain on your equipment
• Compact dimensions of 44.5 (L) x 26.4 (W) x 57.3mm (H) for installation in tight spaces

What's the current rating of this SSR?

This device has a current rating of 12A, so it's a good choice for use in medium-duty tasks.

Crydom Solid State Relay and Accessories

Datasheet

Declaration of Conformity 2014/35/EU

CE Declaration of Conformity (2014/35/EU, 2015/863/EU)
