40FE, Eaton 40A British Standard Fuse, FE, 690 V ac, 500V dc, 63.5mm

Eaton Bussmann Series Bolted Tag Fuse - Fast Acting (FF) HRC Power Fuse Range

Eaton Bussmann Series bolted tag fuse is essentially a fuse that is fitted with brackets, these brackets allow the fuse to be bolted onto a fuse holder. Predominantly this type of fuse is used within installations as a "weak link". They are designed to break when a fault occurs, such as an overcurrent or short circuit - they are a safety and damage protection measure. Cooper Bussman's fuses are commonly found within a multitude of industrial applications, electrical equipment and wiring systems.

Features & Benefits

• Compact dimensions
• Excellent current limiting features
• High-speed clearance of AC and DC faults
• Featured a melt Point Curve Class IEC 269-4
• Fuse links, specifically designed for the protection of applications
• Conforms to industry standards
• Low voltage fuse

Eaton British Standard Fuse, FE, 40A 40FE

Protect your electronic devices from overcurrent and short circuits with this British Standard fuse from Eaton . It's an FF speed fuse, which means it's very fast-acting. When the wire inside the body melts, the circuit is quickly broken to stop equipment from being damaged.
With a current rating of 40A and a voltage rating of 660V AC, this is a low-voltage fuse with reliable current-limiting capability. This makes it an essential safety solution for reduced voltage starters, power drives and converters.

Features & Benefits

• High rupture capacity (HRC) means it blows when high or low current faults occur
• Compact body dimensions of 48mm in height and 17.7mm in diameter for installation in integrated circuits where space is tight
• Voltage rating of 660V AC for compatibility with a wide range of industrial and commercial electrical circuits

How do I mount a bolted tag fuse?

Use the holes in the metal tags to attach it to a fuse block, holder or busbar with a nut and washer. This creates a simple and secure connection to your circuit.

Note

Eaton formerly known as Bussmann

Transition to Bussmann Series

Datasheet - Eaton 40FE
