ASP-134488-01, Samtec ASP Series Straight Surface Mount PCB Socket, 400-Contact, 10-Row, 1.27mm Pitch, Solder Termination

Samtec PCB Socket, 1.27mm Pitch, 56.67mm Length - ASP Series - ASP-134488-01

Need a connection solution for IDC ribbon links between circuit boards? Pick this PCB socket from Samtec to simplify your board-to-board setups. Thanks to its 400 contacts, you can run multiple different connections through this single component. The highly conductive and corrosion-resistant copper alloy contacts transmit signals without a glitch. Mounting is as simple as can be. All you have to do is position the part on your board and solder it in place.

Features & Benefits

• Rigid Vectra housing holds up against warping and wear
• Pitch of 1.27mm is compatible with standard IDC ribbon cables
• Straight body orientation ensures easy alignment on the board

Applications

• Server rooms
• Telecommunications networks
• Industrial control panels
• Medical imaging devices

What header can I mate this PCB socket with?

Pair this component with a compatible Samtec PCB header (227-1635) for optimal performance. After termination, simply plug the header into the socket.

How many rows are the contacts arranged in?

The contacts are arranged in 10 rows, helping you to keep your wire connections organised and compact.
