MUR34107, Schneider Electric Mureva Styl Grey PC Back Box Mounting Frame, 1 Gangs, Выключатель

Schneider Electric Frame, PC Construction, 84mm Width - Mureva Styl Series - MUR34107

Give your switches protection and a neat look with this frame from Schneider Electric. It's an essential finishing touch to reach for when you're installing a light switch or power outlet. As it's made from durable polycarbonate, this unit holds its own against chemicals and mechanical impact, so you can depend on it in industrial settings. This material also serves as an insulator that shields users from electric shocks. Thanks to the flush mounting style, this frame helps keep your assembly discreet.

Features & Benefits

• Can be installed indoors or outdoors for versatility
• IP55 rating means it offers limited protection from dust and low-pressure water jets from any direction
• Reliable in a broad operating temperature range between -5°C and +40°C
• Self-extinguishing properties stop the spread of flames in the event of a fire

Applications

• Entertainment venues
• Medical facilities
• Shopping centres
• Factory floors

What size is this component?

The frame has dimensions of 84 (L) x 84 (W) x 28mm (H) and a projecting depth of 19mm, which means it fits standard light switches and sockets.

Datasheet

Catalogue - Mureva Styl Series Products
