RS PRO Switching Power Supply, 24V dc, 22A, 480W, 1 Output, 90 → 264V ac Input Voltage, Источник питания

RS PRO 480 W Embedded Switch Mode Power Supply SMPS, 24 V DC, Enclosed

This RS PRO 480 W embedded switch-mode power supply (SMPS) will convert mains supplied AC current to provide a safe 24 V DC output suitable for telecoms, manufacturing and machine assembly equipment. This power supply uses a capacitor to maintain its required output voltage. It does this by turning the unit on and off thousands of times a second, helping to transfer power without too much resistance.
The wide input voltage range means it's effective for use in many countries. This SMPS also has a compact chassis-mounting design that makes it ideal for fixing to a base plate or backplate.
Accessible screw terminals also mean installation is easy, while short-circuit and overload protections help to reduce the risk of electrical shock. The unit's safety features meet CE, CB and UL standards and it complies with EN 61000-3-6 on harmonic current emissions, so it's guaranteed not to cause interference with other equipment.

Features and Benefits

• Enclosed package type
• Single output
• Output current of 22 A
• Length of 218 mm
• Width of 116.5 mm
• Depth of 41 mm
• Weight of 8.7 kg
• Input voltage range of 90 to 264 V AC
• Operating temperature range of -30˚C to +70˚C
• Lifetime of 200,000 hours
