The TSZ12x series of high precision operational amplifiers offer very low input offset voltages with virtually zero drift.TSZ121 is the single version, TSZ122 the dual version, and TSZ124 the quad version, with pinouts compatible with industry standards. The TSZ12x series offers rail-to-rail input and output, excellent speed/power consumption ratio, and 400 kHz gain bandwidth product, while consuming less than 40 μA at 5 V. The devices also feature an ultra-low input bias current. These features make the TSZ12x family ideal for sensor interfaces, battery-powered applications and portable applications
Very high accuracy and stability:offset voltage 5 μV max at 25 °C, 8 μV over full temperature range (-40 °C to 125 °C)
Rail-to-rail input and output
Low supply voltage:1.8 - 5.5 V
Low power consumption:40 μA max. at 5 V
Gain bandwidth product:400 kHz
High tolerance to ESD:4 kV HBM
Extended temperature range:-40 to 125 °C
Micro-packages:SC70-5, DFN8 2x2, and QFN16 3x3
