TEC 2-0915, TRACOPOWER TEC 2 DC-DC Converter, 24V dc/ 83mA Output, 4.5 → 13.2 V dc Input, 2W, Through Hole, +95°C Max Temp, Преобразователь

Traco Power DC-DC Converter, 1.6kV DC Isolation Voltage, 2W Power Rating - TEC 2 Series - TEC 2-0915

Take control of the balance of power in your electric circuit with this DC-DC converter from Traco Power. It takes 4.5 to 13.2V DC input voltages and outputs a glitch-free output of 24V DC. An efficiency rating of 85% means it produces minimal heat as it works, so energy waste is minimised, the unit runs cool and you're spared the hassle of installing a heatsink. Thanks to built-in short-circuit protection featuring continuous and automatic recovery, you can rest assured that this converter will pick up where it left off after a supply fault is cleared.

Features & Benefits

• Put a 1.6kV DC isolating barrier between input and output for electrical safety
• Performs reliably in temperatures between -40°C and +95°C
• Non-conductive plastic casing prevents electric shocks

Applications

• Display systems
• Consumer electronics
• Security equipment

How clear are the signals from this DC-DC converter?

Low output ripple and noise of 75mVp-p ensures minimal interference, so you can be sure of clear electrical signals.

How reliable is the converter?

This long-lasting device has a mean time between failures of 6,621,000h.
