TEC 2-2413WI, TRACOPOWER TEC 2WI DC-DC Converter, 15V dc/ 134mA Output, 9 → 36 V dc Input, 2W, Through Hole, +93°C Max Temp, Преобразователь

Traco Power DC-DC Converter, 82% Efficiency Rating, 21.8 (L) x 9.1 (W) x 11.2mm (D) - TEC 2WI Series - TEC 2-2413WI

When your components need a glitch-free power supply, reach for this DC-DC converter from Traco Power. It handles inputs between 9 and 36V DC, transforming them into a stable output of 15V DC. By delivering an isolation voltage of up to 1.6kV DC between the input and output sides, it helps prevent electric hazards from sparking up. This converter is housed in a robust non-conducting plastic case to offer insulation and protection, so it's safe to handle and withstands bumps and scrapes.

Features & Benefits

• Continuous short-circuit protection with automatic recovery for quick restart after a fault
• Efficiency rating of 82% means it runs cool and doesn't need a heatsink
• Low output ripple and noise of 75mVp-p for minimal signal interference
• Mean time between failures of 6,621,000h at +25°C indicates long-term reliability

Applications

• Telecommunications networks
• Electrical engineering
• Factory automation

How quick is this DC-DC converter's startup?

Start-up typically takes between 10 and 20ms, meaning this converter doesn't waste time getting to work.

Does the converter offer shock resistance?

Yes, this unit conforms to the MIL-STD-810F standard, so it resists thermal shock as well as vibration, making it suitable for use with heavy-duty applications.
