AEE02H24-M, Artesyn AEE20W-M DC-DC Converter, 24V dc/ 840mA Output, 18 → 36 V dc Input, 20W, Through Hole, +80°C Max Temp, Преобразователь

1743781
Номер производителя: AEE02H24-MПроизводитель: Artesyn
Цена за шт.
19939.50 руб. (С НДС) *

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

The Artesyn AEE20W-M series is a 20 watt, 2BY1, single output, isolated medical DC-DC converter designed for demanding instrumentation applications that require supplementary or reinforced insulation to comply with stringent industrial or medical safety standards. It has tinned copper pin material, 18-36V input voltage and 24V @ 0.84A output voltage.

4200 Vac reinforced insulation
ƒInsulation rated for 300 Vac working voltage
ƒMedical safety certification
ƒ2x MOPP rated
ƒWide 2: 1 input voltage range
ƒLow leakage current <5 μA
ƒOperating temperature ranging between –40 °C to +85 °C (with derating)
ƒInput filter meets EN 55022, Class A and FCC, Level A
ƒMedical EMC Standard meets 4th Edition of EMI EN55011 and EMS EN60601-1-2
ƒ2”x 1” plastic package
ƒThree-year product warrant

Техническая спецификация
pdfDatasheet
