AEE03A24-M, Artesyn AEE15W-M DC-DC Converter, 5V dc/ 3A Output, 18 → 36 V dc Input, 15W, Through Hole, +80°C Max Temp -40°C, Преобразователь

Artesyn Isolated DC-DC Converter

The Artesyn is a 15W isolated DC-DC converter belongs to the AEE15W-M series. This converter is mounted through-holes. It has an input voltage range from 18V to 36V and the output voltage is 5VDC. It allows nominal voltage for medical applications with 4200VAC reinforced insulation. This product comes in a compact 2in x 1in industry-standard package. The DC-DC converter has a conversion range of 2:1 and fully regulated output voltage regulation. It has an electrical barrier between input and output to improve safety.

Features and Benefits

• Encapsulated
• Single and dual output
• Ripple noise 150mV
• Efficiency up to 89%
• Industry standard 1/2 brick
• Operating temperature ranges between -40°C and 85°C
• Insulation rated for 300VAC
• Low leakage current <5μA
• OCP, OVP, OTP protection
• Remote ON/OFF
• 1in x 2in DIP package
• 3-year warranty

Applications

• Telecommunication equipment
• Industrial equipment
• Consumer electronics

Certifications

• UL approved
• CE certified
