BARTH Touch-Screen HMI Displays

The BARTH DMA-15 connect has a compact 2.4in CAN display. The mini-PLC supports a CAN interface. Its bright, 240x320px TFT display integrates resistive touch technology. Both display design and menu can be selected out of a variety of templates with one single CAN message. This feature ensures that no display programming is necessary. You can fully integrate the DMA-15 within the graphical miCon-L software suite supporting any BARTH mini-PLC with CAN interface.

Features and Benefits

Integrated piezo speaker
Panel-Mount without visible screws
Panel cut-out (LXW): 61mmx46mm
Dimensions (LXW): 69mm x50mm
Operating voltage ranges between 7V and 32V DC open source programming option
Open Source Programming Option
Customized Templates
LED Backlight
Design Template Selection via CAN

Applications

Industrial and building automation
Automotive and maritime technology
Test system control
Technical education/university
