MEAN WELL Switching Power Supply, MPM-20-5, 5V dc, 4A, 20W, 1 Output, 80 → 264V ac Input Voltage, Источник питания

Mean Well Power Switch Mode Power Supply

The Mean Well MPM-20 series 20W single output AC to DC enclosed switch mode power supply has an output current rating of 4A at 5VDC. It has a universal input supply voltage rating ranging from 80VAC to 264VAC.

Features and Benefits

Compact size (2.06in x 1.07in)
EMI class B for class II configuration
Extremely low leakage current
High density
High efficiency up to 85%
High EMC performance
Interior potting
No load power consumption is less than 0.075W
No minimum load required
Operating temperature ranges between -35°C and 85°C
Protection against short circuit, overload, over voltage and over temperature
Vibration resistance is 5G

Applications

Medical computer monitor
Medical examination instrument
Mobile clinical workstation
Portable medical device

Certifications

ANSI/AAMI ES60601-1
EN55011 (CISPR11)
EN55011 (CISPR11)
EN61000-3-2
EN61000-3-3
EN61000-4-11
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
EN61000-4-6
EN61000-4-8
IEC/EN60601-1

Datasheet
