STMicroelectronics LDK320ADU120R, 1 Low Dropout Voltage, Voltage Regulator 200mA, 12 V 3+Tab-Pin, SOT-89, Регулятор напряжения

The LDK320 is a low drop voltage regulator, which provides a maximum output current of 200 mA from an input voltage in the range of 2.5 V to 18 V, with a typical dropout voltage of 100 mV. It is stabilized with a ceramic capacitor on the output. The very good dynamic characteristic, combined with low drop voltage and low quiescent current make it suitable for low power battery-powered applications. The enable logic control function allows the LDK320 to be in shutdown mode by consuming a total current lower than 1 μA.

Input voltage from 2.5 to 18 V
Very low-dropout voltage
Low quiescent current
High PSRR
Low noise
Output current up to 200 mA
Logic-controlled electronic shutdown
Compatible with ceramic capacitor COUT = 1 μF
Current, SOA and thermal protections
Temperature range: -40 °C to 125 °C
