BK9115-AT, BK Precision Digital Bench Power Supply, 80V, 60A, 1-Output, 1.2kW, Блок питания

BK Precision DC Power Supply

The BK Precision 1200W multi-range single-output power DC supply that delivers an output voltage rating of 0V to 80V and a current rating of 0A to 60A. Unlike conventional supplies with fixed output ratings, these multi-range power supplies automatically recalculate voltage and current limits for each setting. This provides a full output power in any V/amp combination within the rated voltage and the current limits. The power supply has a soft panel for remote control, test sequence generation and data logging.

Features and Benefits

Compact, high density, 1U rackmount form factor
High programming and read back resolution
Adjustable voltage slope (rise and fall time)
Sequence programming (internal list mode for models 9115, 9115-AT and 9116)
Save and recall up to 100 instrument settings
Standard USB (USBTMC-compliant), RS-232, GPIB, RS-485 and LAN (9117 only) interfaces supporting SCPI commands for remote control
Analogue interface with control and monitoring functions
Master/slave mode for parallel and series operation
Remote sense
Overvoltage protection
Overpower protection
Over temperature protection
Key-lock function
Efficiency is 75% (220 VAC)
Test functions compliant to automotive standards
Supply voltage rating ranging from 115VAC to 230VAC

Applications

Production testing
Telecommunications
R&D
Service
University labs

Certifications

EN61010-1:2001
EU Low Voltage Directive 2006/95/EC
EMC Directive 2004/108/EC, EN 61000-3-2:2006
EN 61000-3-3:1995+A1:2001+A2:2005
EN 61000-4-2/-3/-4/-5/-6/-11, EN 61326-1:2006
IEC 320

Datasheet

Datasheet

Manual

Datasheet Series BK9115B
