Microchip PIC16F18446-I/P, 8bit PIC Microcontroller, PIC16F, 32MHz, 28 kB Flash, 20-Pin DIP, Микроконтроллер

Microchip Technology Microcontroller

The Microchip technology PIC16F18446-I/P family type, DIP package, through-hole mount, the 20-pin 8-bit microcontroller has a maximum voltage rating of 5.5V. This operates at a maximum speed of 32MHz and features 28kb ISP flash program memory, 2kb of SRAM and 256bytes of EEPROM.

Features and Benefits

• 12-bit ADC with computation (ADC2)
• 4 number of I/O pin
• 5-bit Digital-to-Analogue Converter (DAC)
• Complementary waveform generator (CWG)
• Core Independent Peripherals (CIPs)
• Enhanced mid-range core with 48 instructions, 16 stack levels
• Enhanced Power-ON/OFF-Reset
• EXtreme Low-Power (XLP)
• Four 16-bit timers
• Four 8-bit timers
• Four capture, compare, PWM (CCP)
• Hardware limit timer (HLT)
• IDLE and DOZE low power modes
• In Circuit Serial Programming (ICSP)
• Low-Power Brown-Out Reset (LPBOR)
• Numerically controlled oscillator(NCO)
• Operating temperature ranges between -40°C and 125°C
• Peripheral module disable (PMD) and peripheral Pin Select (PPS)
• Programmable Brown-Out Reset (BOR)
• Two 10-bit PWMs
• Two comparators
• Uses peripherals such as one UART, two-SPI, two-I2C for digital communication
• Window watchdog timer (WWDT)
• Zero cross detect (ZCD)

Applications

• Embed designs
• Household appliances
• Industrial

Datasheet
