RS PRO 24W Plug-In AC/DC Adapter 24V dc Output, 0 → 1A Output, Блок питания

RS PRO 24 V DC Power Supply, 24 W, 0 A → 1 A

Use this RS PRO desktop power supply as a stable source of electricity. It works effectively with a broad range of input voltages (from 100 to 240 V AC) and provides 24 W of continuous DC-current power to your equipment. It's this AC-DC conversion that allows home appliances to connect safely to AC voltage grids.
This unit offers overcurrent and overvoltage protection, which helps stabilise working conditions in high-risk environments to ensure your safety and the longevity of the device. It also automatically recovers in case of short-circuiting, which gives it a longer life. It's the ideal option for powering a computer monitor, a TV or an extractor fan.

Features and Benefits

• Efficiency of 86.2%
• Energy Efficiency Level VI
• Input frequency range of 50 to 60 Hz
• Line regulation range of ±5%
• Load regulation range of ±5%
• Maximum input current of 600 mA
• Output current range of 0 to 1 A
• Output voltage rating of 24 V DC
• Single output
• R/A 2.1 C+ve connection type
• Operating temperature range of 0°C to +40°C
• Width of 50 mm
• Length of 80.6 mm
• Depth of 31 mm
• Low ripple and noise of 200 mV
• Desktop mounting type
• C8 series
