RS PRO 15W Plug-In AC/DC Adapter 5V dc Output, 3A Output

RS PRO 15 W Plug In Power Supply 5 V DC, 3 A, Level VI Efficiency, 1 Output Switched Mode, Type C

Convert AC inputs into DC outputs with this switch-mode power supply from RS PRO. It's designed for both home and business settings, from offices to labs and garages.
This unit is fitted with a compact, built-in wall enclosure and a Type C, EU plug that inserts into standard European mains sockets. For your safety, the supply is protected against overload and overvoltage.
The product has an Energy Efficiency Level VI rating, so it consumes minimal power. It's widely used in a variety of applications, from POS (point of sale) equipment to networking and IT devices.

Features and Benefits

• Ripple and noise of 300 mV
• Input voltage range of 90 to 264 V AC
• Output voltage of 5 V DC
• Output current of 3 A
• Maximum input current of 500 mA
• Single regulated output
• Line and load regulation of ±2%
• Temperature range of 0°C to +40°C
• Power rating of 15 W
• 2.1 x 5.5 x 12 mm centre-positive output connector
• Dimensions of 74.5 (length) x 50.9 (width) x 84.4 mm (depth)
• Weight of 120 g
• Minimum efficiency of 80.59%
• Input frequency range of 47 to 63 Hz
• Mean time between failures (MTBF) of 50000 h
