GRLZ-1/8-B, Festo GRLZ Series Flow Controller, 151188

FESTO Flow Regulators GRLZ Series

One-way flow control or flow control regulator valves, regulate flow rates for the advance or return strokes of cylinders. Restriction of the flow rate of compressed air in exhaust air or supply air direction is used. The GRLZ series feature a one direction non-return function. Flow can be adjusted using the knurled screw or slotted head screw.

Features and Benefits:

• Robust and reliable due to metal design
• Simple and fast mounting
• Pressure control for slow, medium or fast piston movement
• GRLZ series feature threaded or push-in fittings for efficient coupling and uncoupling
• Operated by screwdriver (slot)

Festo Flow Control Valve

The Festo GRLZ series flow control valve is a one-way flow control valve fitting. These valve fittings are combined within a housing. This allows the flow and return speed to be set separately for single and double acting cylinders. The GR series facilitates an efficient and reliable pressure system for compressed air and water. The body material of this valve is zinc die-cast aluminium.

Features and Benefits

• Robust and reliable
• Simple and fast mounting
• Pressure control for slow, medium and fast piston movement
• GRLZ series feature threaded or push-in fittings for efficient coupling and uncoupling
• Operated by screwdriver (slot)

Flow Regulators & Restrictors - Festo

Datasheet

GRLZ-1/8-B Specification Sheet
