KD4-1/4-A, Festo Brass Male Pneumatic Quick Connect Coupling, G 1/4 Male 8mm G 1/4, Муфта

Festo Pneumatic Quick-Connect Coupling Socket, -0.95 to 12 Bar, 1260L/min Flow Rate - KD4-1/4-A

Easily connect your pneumatic equipment to a hose or pipe using this quick-connect coupling socket from Festo. It allows for fast and easy assembly as you can simply push in a quick-coupling plug until you hear an audible click. Thanks to its wide operating pressure range of -0.95 to 12 bar, this versatile unit is suitable for use in both low-pressure and high-pressure applications. A standard nominal flow rate of 1260L/min (litres per minute) makes it a good choice for applications where a high-speed flow is needed. You'll find this component used in situations where you need to change pneumatic tools frequently.

• Lubricated operation possible to reduce mechanical wear and enhance service life
• Broad operating temperature range of -10°C to +60°C for use in demanding environments
• Nickel-plated brass material for strength and resistance to corrosion

Applications

• Automotive industry
• Equipment repair
• Medical devices

What coupling plug can I use with this socket?

This unit is compatible with 8mm quick-coupling plugs from Festo (202-3161), making it easy for you to put together a complete pneumatic coupling system.

Festo Pneumatic Quick Connect Coupling

Datasheet

KD4-1/4-A Specification Sheet

Brochure - Simply Part of the Solution
