RS PRO Axial Fan, 230 V ac, AC Operation, 93.4m³/h, 15W, IP55, 92 x 92 x 38mm, Вентилятор

RS PRO AC Axial Fan, 93.4m³/h, 230 V

This RS PRO AC axial fan keeps your electrical devices cool and in good working condition. It has a high speed of 3150 rpm (revolutions per minute) while operating at a whisper-quiet noise level of 40 decibels (dB), about as loud as a library.
This fan has a strong die-cast aluminium frame, so it remains fixed in place and won't loosen over time. The impeller blades are made from polybutylene terephthalate (PBT), a low-flammability material that provides extra safety.
The fan's motor is impedance protected, meaning will reset automatically if an electrical problem occurs. This prevents damage to the fan, increasing the product's lifespan. As part of our RS PRO range, this component has been tested to ensure quality and reliability.

Features and Benefits

• AC operation
• Airflow of 93.4 m³/h
• Dimensions of 92 (height) x 92 (width) x 38 mm (depth)
• Forward direction of curve
• Fan speed of 3150 rpm
• Ingress Protection (IP) rating of IP55
• Noise level of 40 dB
• Power consumption of 15 W
• Dual ball bearing
• Impedance protected motor
• Shaded pole motor
• Static pressure of 0.22 in H2O
• Supply voltage of 230 V AC
• Lead wire termination type

The RS PRO AC Axial Fan keeps the temperature of your equipment low and prevents the overheating of motors and instruments. The fan's diecast aluminium frame is lightweight, which makes it easy to install at heights or in ceilings and walls. The frame material is also durable and resistant to corrosion, so you can confidently use it in harsher environments like hot and humid industrial kitchens.

Dual ball bearing
Thermally protected motor
Lead wire termination type
