RS PRO Axial Fan, 12 V dc, DC Operation, 90m³/h, 240mA Max, IP55, 92 x 92 x 25mm, Вентилятор

RS PRO 12 V DC, DC Axial Fan, 92 x 92 x 25 mm, 90 m³/h, IP55

This RS PRO axial fan ventilates enclosures and keeps your components cool. Use it to protect your instruments from overheating.
The pre-drilled holes on the frame save installation time and effort. You can be assured that the polybutylene terephthalate (PBT) frame and impeller are lightweight and won't put drag and strain on your electrical cabinets or enclosures. This material is also stain-resistant and easy to wipe clean.
Impedance protection prevents overheating of the fan's motor if it should lock up for some reason. This product carries RoHS (Restriction of Hazardous Substances) certification so contains only negligible amounts of any harmful materials. Install the item in your server cabinets to keep your printed circuit boards (PCBs) ventilated.

Features and Benefits

• DC operation
• Airflow of 90 m³/h
• Dimensions of 92 x 92 x 25 mm
• Forward direction of curve
• Fan speed of 2900 rpm (rotations per minute)
• Ingress Protection (IP) rating of IP55
• Maximum current of 240 mA
• Noise level of 35 dB
• Special features of auto restart motor, brushless DC motor, dual ball bearing and polarity protected motor
• Static pressure of 0.13 in/H2O
• Supply voltage of 12 V DC
• Lead wire termination type

The RS PRO axial fan ventilates enclosures and keeps your components cool. Use it to protect your instruments from overheating. The pre-drilled holes on the frame save installation time and effort. You can be assured that the polybutylene terephthalate (PBT) frame and impeller are lightweight and won't put drag and strain on your electrical cabinets or enclosures. This material is also stain-resistant and easy to wipe clean.

Brushless DC Motor
Dual ball bearing
Operating Temperature: -10C to +70C

OD92255
