2TLA010053R0400 Sentry SSR42 24VDC, ABB Jokab Dual-Channel Safety Switch Safety Relay, 24V dc, 4 Safety Contacts, Реле безопасности

ABB Jokab Safety Relay, 24V DC Supply Voltage, 207g Weight - Sentry SSR42 Series - 2TLA010053R0400

Keep your system safe and sound with this safety relay from ABB Jokab. It detects potential faults in your circuit to prevent machinery from starting up in hazardous conditions. For versatility, the unit features two NO and two delayed NO contacts. Thanks to the handy switch on the front, you can choose between a manual or automatic reset function, so you have complete control at your fingertips. A supply voltage of 24V DC means it's just the thing for use in low-power equipment.

Features & Benefits

• OFF-delay time of 1.5 seconds allows machinery to come to a complete stop to minimise the risk of damage
• IP20 rating indicates it's touch-proof and protected against objects larger than 12mm in size
• Screw terminals offer a secure and reliable electrical connection

Applications

• Industrial automation
• Assembly lines
• Food and beverage production
• Pharmaceutical manufacturing

How large is this safety relay?

This safety relay has compact dimensions of 120 (L) x 22.5 (W) x 120mm (H), so you can easily install it in areas with limited space.

Datasheet

Catalogue - Safety Products

Line Drawing - Sentry Safety Relays

Datasheet - 2TLA010053R0400 Sentry SSR42 24VDC

Manual - SSR42
