RS PRO 6 Outlet Manifold, G 3/8 G 1/4, Фитинг

RS PRO Aluminium Pneumatic Manifold Tube-to-Tube Fitting, 6 Outlet Ports, 1/4 in Female

Need to supply air or gas to multiple lines? Use these RS PRO pneumatic manifold fittings with six 1/4-in female outlet ports to connect up to six valves, pipes or tubes. They're suitable for all fluids, so they're a versatile choice.
The fittings are made from aluminium, meaning they're lightweight yet durable. They have a maximum operating temperature of +300°C and a maximum operating pressure of 75 bar, so they can withstand harsh industrial conditions.
These manifolds are a compact solution for organising multiple tubes in a pneumatic or hydraulic system with minimal loss of pressure. You'll find them used for automated equipment in garages, water treatment plants and industrial vacuum pumps.

Features and Benefits

• Female 3/8 in threaded inlet ports
• Inlet port thread size of 3/8 in British Standard Pipe (BSP)
• Female 1/4 in threaded outlet ports
• Outlet port thread size of 1/4 in British Standard Pipe (BSP)
• Aluminium material
• Maximum operating pressure of 75 bar
• Maximum operating temperature of +300°C
• Two inlet ports
• Six outlet ports
• Meets 1907/2006 Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) and Pressure Equipment Directive (PED) 2014/68/UE standards
