RS PRO Push-in Fitting, R 1/8 Male to Push In 6 mm, Threaded-to-Tube Connection Style, Угловой фитинг

RS PRO Elbow Threaded Adaptor, R 1/8 Male to Push-In 6 mm, 20 bar

This RS PRO adaptor connects pneumatic air pipes at a right angle. Its shape allows you to connect hoses without bending them so there's less risk of damage to your tubes.
The adaptor is fitted with a stainless steel washer that firmly clamps around a hose without the risk of puncturing your pipes. Its light technopolymer body won't put a strain on tubing or pull it loose.
It's durable enough to offer safe use with compressed air and gas lines in harsh environmental conditions. The connector's tightness means you can attach pneumatic pipes to impactful air-powered tools like jackhammers.

Features and Benefits

• Angle of 90°
• Threaded-to-tube connection style
• Connector A is a male, threaded R 1/8 type
• Connector B is a 6 mm push-in type
• Maximum operating pressure of 20 bar
• Maximum operating temperature of +80°C
• Minimum operating temperature of -20°C
• Elbow threaded adaptor pneumatic fitting type
• Complies with 1907/2006 (REACH), ISO 14743:2004 and PED 2014/68/UE standards
• Swivel connection
• Brass thread material
• R 1/8 male threaded connection
• Push in 6 mm tube connection
