RS PRO Push-in Fitting, Push In 6 mm to Push In 4 mm, Tube-to-Tube Connection Style, Фитинг

RS PRO Straight Tube-to-Tube Adaptor, Push In 6 mm to Push In 4 mm, 20 bar

Looking for a way to connect two hoses together? This RS PRO tube-to-tube adaptor comes with push-in connectors that allow you to add or remove your tubes with ease. This part is frequently used in robotics, vehicle manufacturing and repair shops.
This easy-to-use unit is made of technopolymer, which is well-suited for use in demanding environments as it's tough and handles a temperature range of -20ºC to +80ºC. It's also silicone-free, which stops grit and grime from sticking to the surface.
This part is Restriction of Hazardous Substances (RoHS) compliant, meaning it contains only minimal levels of any harmful materials. It's commonly used to connect tubes for transporting industrial water because of its corrosion resistance.

Features and Benefits

• Straight tube-to-tube pneumatic adaptor
• Connector A has a diameter of 6 mm
• Connector B has a diameter of 4 mm
• Push-in connectors
• Maximum operating pressure of 20 bar
• Operating temperature range of -20°C to +80°C

RS PRO Datasheet

Pneumatic Linecard

RS PRO Pneumatics Range Overview
