1829358, Phoenix Contact 3.81mm Pitch 3 Way Pluggable Terminal Block, Feed Through Header, Panel Mount, Solder/Slip on

1761435
Номер производителя: 1829358Производитель: Phoenix Contact
Цена за шт.
1665.30 руб. (С НДС) *

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

Phoenix Contact Feed-Through Terminal Block, 3 Way, 30 to 10AWG - DFK-MC 1.5/ 3-GF-3.81 - 1829358

Directly connect two conductors to each other using this feed-through terminal block from Phoenix Contact. It's a single-row unit that features three contacts, so it can accommodate multiple wires at the same time. As the contacts are made from copper alloy, they have high electric conductivity and support stable current transmissions. For added durability, the contacts come with robust tin plating, which is resistant to impact and corrosion.
You can securely attach this unit to your board using the screwable tension sleeve, ensuring mechanical stability even in vibrating conditions. Thanks to the built-in flexible side panels, you can also mount it on a wall, making it a versatile option. Its rugged polyamide housing offers insulation protection to prevent electric hazards. You'll typically find terminal blocks like this one used in consumer electronics and industrial machinery.

• Flammability rating of UL94 V-0 means burning stops in 10 seconds to stop fire from spreading
• Rated surge voltage of 6kV to handle current overload
• Maximum load current of 20A to withstand high-current systems
• Broad operating temperature range between -40°C and +100°C for use in harsh environments

Техническая спецификация
pdfDatasheet
pdfDimension Sheet - 1829358
pdfCatalogue - Terminal Block
Кол-во контактов:
3
Количество рядов:
1
Концевая заделка:
Solder/Slip on
Материал:
PA (Insulate)
Номинал тока:
8A
Номинальное напряжение:
160 В
Ориентация корпуса:
Прямой
Серия:
DFK-MC 1.5/ 3-GF-3.81
Тип монтажа:
Крепление на панель
Тип съемного клеммного блока:
Feed Through Header
Цвет:
Зеленый
Шаг:
3.81мм
