1840560, Phoenix Contact 7.62mm Pitch 3 Way Pluggable Terminal Block, Feed Through Header, Cable Mount, Panel Mount, Screw

1761445
Номер производителя: 1840560Производитель: Phoenix Contact
Цена за шт.
2312.70 руб. (С НДС) *

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

Phoenix Contact 3-pin Feed-through Terminal Block, 7.62 mm Pitch – DFK-PC 4/3-GF-7.62 – 1840560

This feed-through terminal block from Phoenix Contact provides reliable connections between wires and components in your electronic circuitry. For easy installation, simply mount it directly onto your printed circuit board (PCB) and secure it with a screwable tension sleeve. The product also features flexible side panels, which will allow you to mount it on a wall. Its contacts are tin-plated, so they're durable and long-lasting.
The block has a high voltage rating of 1 kV, making it suitable for a broad range of demanding electrical applications such as domestic or commercial wiring. Its green polyamide material has a UL (Underwriter Laboratories) 94 V-0 certification, indicating it will burn for no more than 10 seconds if exposed to a naked flame.
Feed-through blocks like this one are commonly used in household appliances, industrial equipment and electronic devices.

• Straight body orientation
• Male gender
• Panel mounting type
• 3 contacts
• 1 row
• Pole format of 3P
• Screw termination method
• Feed-through header
• Current rating of 20 A
• Pitch of 7.62 mm
• Dimensions of 32 (length) x 44.48 (width) x 30.5 mm (depth)

Feed-through header, nominal current: 20 A, rated voltage (III/2): 630 V, number of positions: 3, pitch: 7.62 mm, connection method: Screw connection with tension sleeve, colour: green, contact surface: Tin, mounting: Direct mounting

Техническая спецификация
pdfDatasheet
pdfDimension Sheet - 1840560
pdfCatalogue - Terminal Block
Кол-во контактов:
3
Количество рядов:
1
Концевая заделка:
Винт
Материал:
PA (Insulate)
Номинал тока:
20A
Номинальное напряжение:
630 В
Ориентация корпуса:
Прямой
Серия:
DFK-PC 4/ 3-GF-7.62
Тип монтажа:
Кабельный монтаж, Панельный монтаж
Тип съемного клеммного блока:
Feed Through Header
Цвет:
Зеленый
Шаг:
7.62мм
