1825608, Phoenix Contact 5.08mm Pitch 12 Way Pluggable Terminal Block, Inverted Plug, Cable Mount, Screw Termination

Phoenix Contact 12-pin PCB Terminal Block, 5.08 mm Pitch - IC 2.5/12-STGF-5.08 - 1825608

When you need a simple way to join multiple wires on a printed circuit board (PCB), choose this feed-through terminal block from leading manufacturer Phoenix Contact. It's made from flame-retardant polyamide material and provides an insulated connection for up to 12 wires.
As the block is cable mounted, it gives you the flexibility to make changes to the connection or PCB as needed. You can secure the wires with screws, creating a reliable bond. The standardised connector means the device is suitable for international use. Durable green polyamide housing is resistant to warping, so it can stand up to demanding industrial environments.
PCB blocks such as this one are used in a range of settings, from control and automation to signal applications that need several connections.

• Straight body orientation
• Current rating of 12 A
• Dimensions of 19.2 (length) x 71.08 (width) x 15 mm (depth)
• Male gender
• Cable mounting type
• 12 contacts
• 1 row
• Pitch of 5.08 mm
• Pole format of 12P
• Screw termination method
• Voltage rating of 630 V

PCB connector, nominal current: 12 A, rated voltage (III/2): 320 V, number of positions: 12, pitch: 5.08 mm, connection method: Screw connection with tension sleeve, colour: green, contact surface: Tin
