AX103114, Belden KeyConnect Series Cat5e, Cat6 24 Port Keystone Patch Panel 1U Black, Коммутационная панель

The 10GX Patch Panel is a fully loaded patch panel designed to be used within the 10GX System. The 10GX Patch Panel features the 10GX Connector, specifically designed to meet the difficult challenges of10 Gb/s transmission. 10GX Patch Panels are available in high-density options such as 24 ports in 1U or 48 ports in 2U, but the phenomenal ANEXT performance of the 10GX Connector has allowed Belden to also support an ultra high-density option offering the 10GX Ultra High-Density Patch Panel supporting 48 ports in 1U. All performance characteristics including ANEXT, NEXT, FEXT, Insertion Loss and Return Loss have been set to guarantee transmission performance up to 625 MHz. KeyConnect Patch Panels are robust all-metal modular patch panels that provide a flexible,versatile and high-density termination solution for Data Center and Telecommunications Room installations. The modular KeyConnect Patch Panels are available in 24-port/1U, 48-port/2U, 72-port/2U and 48-port/1U configurations.The KeyConnect Patch Panel series also includes the unique AngleFlex Patch Panel available in 24-port/1U and 48-port/2Uconfiguration.Patent-pending removable angled inserts provide intuitive left, right or bi-directional patch cord routing and more efficientswitch connection. Angled inserts eliminate the need for horizontal cable management, for a 27% space savings per rack.The KeyConnect and AngleFlex panels can be configured using 10GX Key Connect Modular Jacks or Multimedia Modules.The KeyConnect Front Access Patch Panels are available in 24-port/1U, 48-port/2U, and 72-port/2U configurations and are designed for applications where space is limited behind the panel

Datasheet
