RS PRO Pure Sine Wave 1500W Power Inverter, 12V Input, 230V Output, Инвертор

RS PRO 1500 W Fixed Installation DC-AC Power Inverter, 12 V / 230 V

This fixed installation DC to AC power inverter from RS PRO is a compact electrical device that can be fitted onto car batteries and used to charge appliances.

Blenders, laptops and other devices that plug into wall outlets run on alternating current (AC), while car batteries generally produce direct current (DC). So if you need to charge devices on the road or from a mobile home, DC to AC power inverters are just the thing.

This 1500 W inverter is lightweight and simple to operate, with a chassis mount that fits easily to your vehicle’s battery. It generates pure sine wave – a smoothly varying AC that works best with delicate equipment like computers and radios. An anodised aluminium case provides durability and excellent heat dissipation.

Tested to the high standards of all products in the RS PRO range, this power inverter is protected against overheating, overloading and short circuiting.

Features and Benefits

• DC-AC power inverter
• Chassis mounting
• Two output connections
• Single-phase electrical output
• Input voltage of 12 V
• Output voltage of 230 V
• Continuous output power of 1500 W
• Intermittent output power of 1600 W
• Surge power of 3000 W
• Universal output connection type
• Efficiency rating over 90%
• Output current of 13.4 A
• Maximum input current of 250 A
• Mean time between failures of 50,000h
• Length of 372 mm
• Width of 230 mm
• Depth of 107.7 mm
• Weight of 4.7 kg
• Operating temperature range of -20°C to +50°C
• Output frequency range of 50 Hz
• Conforms to standards ECE R10.05:201 and EN 61000-6-3 on electromagnetic compatibility
• Meets EN 60950-1 on safe information technology equipment
• Conforms to Electrostatic Control Standards ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007
• RoHS (Restriction of Hazardous Substances) compliant
