RS PRO Pure Sine Wave 3000W Power Inverter, 12V Input, 230V Output, Инвертор

3000 W Fixed Installation DC-AC Power Inverter, 12 V / 230 V

The RS PRO fixed installation DC-AC power adapter converts direct current (DC) to alternating current (AC) to run numerous electrical appliances. It outputs 3000 W of power as a pure sine wave, which many electrical products are designed to work best with.

Housed in an anodised aluminium case, this durable adapter dissipates heat well. It's compact, lightweight and easy to operate, with indicator lights showing when it's working properly. A soft-start mechanism limits the inrush current, preventing jerky operation and sudden mechanical stresses on machinery.

The power inverter is protected against overheating and overload, as well as over-voltage, short circuiting and reverse polarity. A low-voltage alarm shuts the adapter down if needed. Comprehensively tested by engineers, it conforms to standards EN 61000-6-3 (electromagnetic compatibility) and EN 60950-1 on safe information technology equipment.

This type of adapter is used in applications including uninterruptible power supplies, refrigeration compressors and induction heating.

Features and Benefits

• Fixed installation DC-AC power inverter
• Chassis mounting
• Universal output connection type
• 2 output connections
• 5 V, 2.1 A USB port
• Single-phase output
• Continuous power output of 3,000 W
• Intermittent power output of 3,100 W
• Pure sine wave output is optimal for many electrical products
• Output current of 26.9 A
• Output frequency of 50 Hz ±3
• Input voltage of 12 V
• Output voltage of 230 V
• Maximum input current of 500 A
• Maximum operating temperature of +50˚C
• Minimum operating temperature of -20˚C
• >
90% efficiency
• Length of 488 mm
• Width of 230 mm
• Depth of 107.7 mm
• Weight of 7,710 g
• Mean time between failures of 50,000 h
• Indicator lights show when the adapter is working properly
• Conforms to standards ECE R10.05:201 and EN 61000-6-3 on electromagnetic compatibility
• Meets EN 60950-1 standard on safe information technology equipment
• Conforms to Electrostatic Control Standards ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007
• RoHS (Restriction of Hazardous Substances) compliant
