MMCX-P-C-H-RA-CA1, Samtec MMCX Series, Plug PCB Mount MCX Connector, 50Ω, Solder Termination, Right Angle Body, Разъем

Samtec MMCX Plug PCB Mount MCX Connector, 50Ω, Solder Termination - MMCX-P-C-H-RA-CA1

This is a 50 Ohm MMCX switchable jack designed by Samtec. It features a drop-through edge mount and can be soldered to a PCB on either the right or left side. This versatile connector switches from an internal to an external antenna when the cable is mated. It offers reliable performance up to 6 GHz and is available in a non-magnetic option suitable for medical and aerospace applications

Features & Benefits

• Seamlessly transitions between internal and external antennas, ensuring optimal signal reception
• Easy installation and secure attachment to the PCB
• Performance to 6 GHz which is suitable for high-frequency applications

Applications

• Used in mobile phones, routers, and other wireless devices
• Ensures accurate signal testing and measurement
• Reliable connectivity in demanding environments

What is the impedance of the MMCX-P-C-H-RA-CA1?

The MMCX-P-C-H-RA-CA1 has a 50 Ohm impedance.

Can I use this connector for high-frequency applications?

Yes, the MMCX-P-C-H-RA-CA1 is designed for performance up to 6 GHz.
