FTSH-105-01-L-DV-K-P-TR, Samtec FTSH Series Straight Through Hole Pin Header, 10 Contact(s), 1.27mm Pitch, 2 Row(s), Unshrouded

1802905
Номер производителя: FTSH-105-01-L-DV-K-P-TRПроизводитель: Samtec
Цена за шт.
1119.30 руб. (С НДС) *

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

Samtec FTSH Series Pin Header, Gold Contact Plating, 3.4A - FTSH-105-01-L-DV-K-P-TR

This Samtec pin header with a 1.27 mm pitch from the FTSH series, model FTSH 120 01 F DV, is a versatile connector suitable for various applications in automation, electronics, electrical, and mechanical industries. Designed with high quality materials and precise specifications, this pin header offers reliable performance and durability.

Features & Benefits

• Straight pin header design for easy wire to board connection
• Features a through hole mounting type for secure installation
• Constructed with phosphor bronze contacts for enhanced conductivity
• Gold plated pins ensure excellent signal transmission and resistance to corrosion
• Can handle high current ratings up to 3.4 A, suitable for demanding applications
• Comes with 10 pins in 2 rows, providing flexibility in connectivity
• Unshrouded design for easy accessibility and connection
• Offers a pitch of 1.27 mm, ideal for compact and space constrained applications
• Solder termination method for a strong and reliable connection

Applications

• Ideal for use in PCB assemblies in automation and electronics applications
• Suitable for connecting various components in electrical equipment
• Perfect for board-to-board connections in mechanical systems
• Can be used in industrial control systems for reliable signal transmission
• Suitable for applications requiring a secure and high-current connection

Can it handle high current ratings effectively?

Yes, the Samtec pin header is designed to handle high current ratings of up to 3.4 A, making it ideal for demanding applications.

Is the connector suitable for through-hole mounting?

Yes, this pin header features a through-hole mounting type, ensuring a secure and stable connection in your application.

Will the gold-plated pins provide reliable signal transmission?

Yes, the gold-plated pins offer excellent conductivity and resistance to corrosion, ensuring reliable signal transmission.

Can it be used for wire-to-board connections?

Yes, this pin header is designed for wire-to-board connections, making it suitable for various connection scenarios in your application.

Is the pitch of 1.27 mm suitable for compact applications?

Yes, the 1.27 mm pitch of this pin header makes it ideal for compact and space-constrained applications where precision is essential.

Техническая спецификация
pdfDatasheet
pdfLine Drawing - FTSH-105-01-L-DV-K-P-TR
pdfBrochure - Rugged/Power Interconnect Solutions
pdfCatalogue - A Different Breed of Cat
Длин хвостового штыря:
0.1мм
Длина соединительного штыря:
3.05мм
Защищенный/Незащищенный:
Unshrouded
Кол-во контактов:
10
Количество рядов:
2
Концевая заделка:
Припой
Материал контактов:
Фосфорная бронза
Номинал тока:
3.4A
Ориентация корпуса:
Прямой
Покрытие контактов:
Золото
Серия:
FTSH
Система соединителя:
Wire to Board
Тип монтажа:
Сквозное отверстие
Шаг:
1.27мм
