MLP1-SMMC0AC, Sick MLP1 Solenoid Interlock Switch 24 V

The MLP1 is an interlocking device with a locking device consisting of a non-contact sensor with locking solenoid and a coded actuator. The actuator has a low coding level.
If the protective device is closed, the actuator approaches the sensor. If the actuation field is reached, the actuator code is read out and evaluated by the RFID sensor. If the code is valid, the safe output signal switching device (OSSD) switches.
If the locking solenoid is supplied with power, the locking device is active.
The MLP1-SMMC0AC is designed for series connection of MLP1 devices.

Magnetic locking function prevents the protective door from being opened and therefore avoids unwanted interruption to the production process
Maximum safety for door monitoring with two self-monitored semiconductor outputs (OSSDs)
High level of machine availability due to large door offset tolerance
Long product service life due to low-wear and low-maintenance configuration
Discreet integration into the machine design thanks to innovative mounting option
Quick connection and simple cascading via M12 plug connector reduce costs and the amount of wiring required
Flat actuator without protruding parts minimizes risk of injury
