109P0405H601, Sanyo Denki 109P Series Axial Fan, 5 V dc, DC Operation, 13.6m³/h, 1.6W, 320mA Max, 40 x 40 x 20mm, Вентилятор

Sanyo Denki Axial Fan, 8000rpm Speed, 0.32A Current Rating - San Ace 109P Series - 109P0405H601

This axial fan from Sanyo Denki helps your system keep its cool. Thanks to its high speed of 8000rpm, it ensures powerful air circulation to prevent your equipment from overheating. It features protection against reverse polarity and locked rotor burnout for enhanced electrical safety. A low sound output of 33dB means it won't be a nuisance in your work environment. A robust lifespan of 40,000 hours at +60°C means you can count on it for the long haul.

Features & Benefits

• Built-in pulse sensor keeps track of rotation speed for enhanced efficiency
• Frame and impeller are made from non-flammable plastic for safety in the event of a fire
• Operating voltage range of 4.5 to 5.5V DC for use in low-power applications
• Compact frame dimensions of 40 (L) x 40 (W) x 20mm (D) for installation in small enclosures

Applications

• Electrical cabinets and enclosures
• Server racks
• Factory automation

What temperatures can I use this axial fan in?

This axial fan has a wide operating temperature range between -20°C and +70°C, so it won't let you down in harsh environments.
